3308-BD-XL
Angular contact ball bearing
Angular contact ball bearing 33..-BD-XL, double row, X-life, steel sheet metal cage
Replaces
3308-BD
Preferred product
Main Dimensions & Performance Data
| d | 40 mm | Bore diameter |
| D | 90 mm | Outside diameter |
| B | 36,5 mm | Width |
| Cr | 67.000 N | Basic dynamic load rating, radial |
| C0r | 48.500 N | Basic static load rating, radial |
| Cur | 3.350 N | Fatigue load limit, radial |
| nG | 8.000 1/min | Limiting speed |
| nϑr | 7.000 1/min | Reference speed |
| ≈m | 0,99 kg | Weight |
Mounting dimensions
| da min | 49 mm | Minimum diameter shaft shoulder |
| Da max | 81 mm | Maximum diameter of housing shoulder |
| ra max | 1,5 mm | Maximum fillet radius |
Dimensions
| rmin | 1,5 mm | Minimum chamfer dimension |
| D1 | 77,02 mm | Shoulder diameter outer ring |
| D2 | 79,92 mm | Caliber diameter outer ring |
| d1 | 58,99 mm | Shoulder diameter inner ring |
| d2 | 56,82 mm | Caliber diamter inner ring |
| a | 53,1 mm | Distance between the apexes of the pressure cones |
| α | 30 ° | Contact angle |
Temperature range
| Tmin | -30 °C | Operating temperature min. |
| Tmax | 120 °C | Operating temperature max. |
Operating conditions for bearing 3308-BD-XL
