Axial deep groove ball bearing
Axial deep groove ball bearing 523, double direction, steel sheet metal cage
Main Dimensions & Performance Data
| d | 70 mm | Inner diameter shaft washer |
| D | 150 mm | Outer diameter housing washer |
| T2 | 87 mm | Höhe |
| Ca | 186.000 N | Basic dynamic load rating, axial |
| C0a | 420.000 N | Basic static load rating, axial |
| Cua | 17.700 N | Ermüdungsgrenzbelastung, axial |
| nG | 2.260 1/min | Limiting speed |
| nϑr | 4.150 1/min | Bezugsdrehzahl |
| ≈m | 6,202 kg | Weight |
Mounting dimensions
| da max | 85 mm | Maximaler Durchmesser der Wellenschulter |
| Da max | 111 mm | Maximaler Durchmesser der Gehäuseschulter |
| ra max | 1,5 mm | Maximaler Hohlkehlradius |
| ra1 max | 1 mm | Maximaler Hohlkehlradius |
Dimensions
| D1 | 88 mm | Inner diameter housing washer |
| B | 19 mm | Höhe der Wellenscheibe |
| rmin | 1,5 mm | Minimaler Kantenabstand |
| r1 min | 1 mm | Minimaler Kantenabstand |
Temperature range
| Tmin | -30 °C | Betriebstemperatur min. |
| Tmax | 150 °C | Betriebstemperatur max. |
Calculation factors
| A | 1,1 | Minimallastfaktor |
