OPTIME-SET-AWX5-EX-GLB2
Wireless condition monitoring sensor
Wireless condition monitoring sensor measuring acceleration and temperature, non-replaceable battery, supports Wirepas mesh-network
Part of OPTIME Solutions – Additional products required for operation, additional recurring charges per active sensor apply.
Measurement
| fl | 2 Hz | Lower frequency limit |
| fh | 5.000 Hz | Upper frequency limit |
| amax | 16 | Amplitude range ± |
3 | Number of measurement axis | |
RMSLow, RMSHigh, ISO, KurtosisLow, KurtosisHigh, H | Calculated KPI | |
Yes | Time waveform | |
| ≈m | 0,1 kg | Weight |
Communication
| f | 2,4 GHz ISM band | Frequency band communication, sensor - gateway |
| l | 100 m | Sensor range (line of sight) |
per NFC | Sensor activation |
Main Dimensions & Performance Data
| h | 86,04 mm | Sensor height (with bolt) |
| b1 | 32,58 mm | Sensor width (1) |
| b2 | 30,64 mm | Sensor width (2) |
Technical data
| Tmax | 85 °C | Upper temperature limit |
| Tmin | -40 °C | Lower temperature limit |
IP 69K | Ingress protection | |
| tbat | 5 | Calculated battery life |
Downloads:
Your current product variant
| Region | GLB2 | EU, world (2) |
| Measurement types | Vibration, Temperature | Vibration, Temperature |
| Communication sensor - gateway | Wirepas | Wirepas mesh network |
| Mounting bolt | M6 | DIN13-1 metric thread |
| Explosion Protection | Zone 1 | Zone 1/21 |
